COBRA Stage I and II Siphon
click on image for larger view
COBRA Stage I and II Siphon
Cobra Stage I and II All New for 2018
The two (2) Cobra models are 100% welded, include a negative pressure dust collector using MERV tested and certified cartridge filtration. The Cobra’s are the best of the smaller compact models using 16 or 22 cfm of compressed air.
More Industrial features added to these lower cost models for a cleaner workspace!
- Product Info
Need help finding the right machine? CONTACT our sales department.
-
Have a Question? Ask a Specialist
-
- 13” x 24” ClearView™ Window
- Low Static Window Protector Glass
- Window Sweep
- Advanced LED Lighting
- 8” Work Ports
- All Air Controls
- Blow-Off Gun
- Abrasive Flow Control Mixing Valve
- Tungsten Carbide Nozzle
- Leg Leveling Pads
- Right and Left Side Access Door
- Tool-Less Window Replacement
- Large Hopper Drain
- Vertical Flow Control Mixing Valve Sump with Drain
- Foot Operated Blast
- Patented Separator Reclaimer
- Negative Pressure Dust Collector, 100% Welded
- 90 sq.ft. MERV Tested Filter Cartridges
- Manually Cleaned Cartridge Rapper (Stage I)
- Vibrator Cleaned Cartridges (Stage II)
- Large Dust Storage Hopper
- Dust Collector Service Door
- 350 cfm Blower Stage I
- 500 cfm Blower Stage II
- 16 cfm Gun (Stage I)
- 22 cfm Gun (Stage II)
- Tungsten Blasting Nozzle
Cobra Stage I & II Siphon
Inside Cabinet
42”W x 24”D x 26”H
Overall Cabinet
47”W x 37”D x 82”H
Door
20” x 21-3/4”H
Air Usage Stage I
16 CFM @ 80 PSI
Air Usage Stage II
22 CFM @ 80 PSI
Electrical
120 Volt-60Hz
Dust Collector
Cartridge 90 Sq.Ft.
Dust Collector Blower stg.I
350 CFM @ 1” S.P.
Dust Collector Blower stg. II
500 CFM @ 1” S.P.
Dust Collector
Dust Storage Hopper
Dust Collector
Service Access Door
Shipping Weight Stage 1
400 Lbs.
Shipping Weight Stage 2
425 Lbs.
